YM Series of Hydraulic Cathead
Product Detail
YM Series of Hydraulic Cathead
Technical Features
l The YM hydraulic cathead is applicable to make up and break out by companying with Rotary Tong.
l Operation is stable and pull may be adjusted whenever necessary.
l It has its series with four specifications of 5t, 8t, 10t, 16t by pull to select.
Technical Parameters
Model | YM-5 | YM-8 | YM-10 | YM-10C | YM-16C | YM-16Z | |
Pressure rating | MPa | 16 | 16 | 16 | 16.6 | 16.6 | 16.6 |
Psi | 2320 | 2320 | 2320 | 2400 | 2400 | 2400 | |
Plow rating | L/min | 120 | 120 | 120 | 120 | 120 | 120 |
gpm | 31.7 | 31.7 | 31.7 | 31.7 | 31.7 | 31.7 | |
Nominal stroke | mm | 1700 | 1400 | 1650 | 1500 | 1500 | 1500 |
in | 67 | 55 | 65 | 59 | 59 | 59 | |
Pull rating | kN | 50 | 80 | 100 | 100 | 160 | 160 |
US ton | 5.5 | 8.8 | 11 | 11 | 17.6 | 17.6 | |
Wire rope diameter | mm | 16 | 20 | 22 | 20 | 26 | 26 |
in | 5/8 | 3/4 | 7/8 | 3/4 | 1 1/32 | 1 1/32 | |
Size | mm | 2232*11172*650 | 2280*1280*650 | 1973*710*430 | 2137*725*260 | 2314*740*400 | 1592*650*520 |
in | 88*46*26 | 90*50*26 | 76*28*17 | 91*29*10 | 91*29*16 | 63*6*21 | |
Weight | kg | 288 | 345 | 530 | 360 | 400 | 520 |
lb | 635 | 761 | 1168 | 794 | 882 | 1146 | |
