RSG216-110 Iron Roughneck
Product Detail
RSG216-110 Iron Roughneck
Technical Features
l RSG216-110 iron roughnecks are a convenient modularized product and used for make-up and break-out operations of drill pipes. Drill collars, casings and other type couplings from 31/2” to 81/2”.
l It is an upgrade product that suits for hot or cool environment, onshore or offshore location.
l Iron roughneck can be remote controlled. It is designed and manufactured according to API spec 7k “Specification for Drilling and well servicing Equipment”.
Technical Parameters
Size range | mm | 88.9 - 216 |
In | 3 1/2 - 8 1/2 | |
Speed | rpm | 80 |
Spin torque | N.m | 3050 |
ft.lbf | 2250 | |
Make up torque | N.m | 81350 |
ft.Ibf | 60000 | |
Break out torque | N.m | 10865 |
ft.lbf | 80000 | |
Weight | kg | 3450 |
lb | 7600 |
